HP Agilent Keysight, 8562E


HP Agilent Keysight, 8562E
Le foto sono di repertorio e potrebbero non corrispondere all'oggetto realmente venduto, come pure le opzioni installate. Su richiesta verranno fornite foto in alta risoluzione e opzioni reali dell'oggetto in vendita.
Descrizione del prodotto

The Keysight 8562E is a high-performance spectrum analyzer that provides the frequency and dynamic range (DANL: -151 dBm) needed for today's high-speed digital wireless communication applications. It allows manufacturing and R&D engineers to test network components with state-of-the-art performance.

The 8562E has a frequency range of 30 Hz to 13.2 GHz, which covers the spur-search ranges specified by leading standards organization in Europe and the United States for GSM. With its fast DLP execution speed, Keysight 8562E reduces your test times in production.

  • Continuous 30 Hz to 13.2 GHz sweep
  • Resolution bandwidths of 1 to 100 Hz digitally implemented for measurement speed
  • Low phase noise and wide dynamic range
  • Precision timebase and 1 Hz counter resolution
  • Adjacent channel power, channel power, carrier power, and gated video measurements standard
  • Range di Frequenza: 30 Hz - 13.2 GHz
  • RBW: 1 Hz to 1 MHz in a 1, 3, 10 sequence and 2 MHz
  • VBW: 1 Hz to 3 MHz in a 1, 3, 10 sequence
  • Max Displayed average noise level: 151dBm (10 MHz - 2.9 GHz)
  • Dynamic range: >148 dB (2.9 - 6.46 GHz)
  • Demodulatore: AM-FM
  • Demodulatore: AM-FM
  • Frequenza massima: 13.2 GHz
  • Frequenza minima: 30 Hz
  • Livello massimo: +30 dBm
  • Risoluzione minima: 1 Hz
