Wandel & Goltermann (Acterna), PFA-35

You are here: Telecom » Trasmission analyzer

Wandel & Goltermann (Acterna), PFA-35
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
WG PFA-35 is a multi-purpose instrument designed for commissioning,maintenance and troubleshooting on digital networks. It is used to carry out both framed and unframed tests on a wide variety of equipment such as primary multiplexers, X.50 multiplexers, digital cross connects, automatic protection switches and circuits operating at speeds from 50 bit/s to 2048 kbit/s. WG PFA-35 can be configured as a DCE as well as a DTE; this allows a data circuit to be taken out of service and tested in sections so that a fault can be isolated to a specific part of the circuit.The WG PFA-35 has 4 built-in interfaces which can be further supplemented by means of cable adaptors allowing testing at 7 different types of interface.
Features
  • Multi-interface capability: V.24/RS232, V.11/X.24, V.35,V.36/RS449, G.703 co-dir, G.703 (2048/704 kbit/s)
  • X.50 simulation and analysis (64 kbit/s and 2 Mbit/s)
  • Primary Mux/Demux measurements
  • Sa bit, monitoring and generation
  • V.24/RS232 Remote operation
