HP Agilent Keysight, N4413A
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description

The Agilent N4413A S-parameter test set is a key component of an Agilent balanced-measurement system. When combined with an Agilent 8753C (3 GHz Rev.04.13)-D-E-ES Options 006 and 011 vector network analyzer and an external PC equipped with an IEEE-488 GPIB card, this test set makes characterizing fully balanced or balanced-to-single-ended RF components a lot easier. Devices such as differential filters or amplifiers, baluns, and balanced transmission lines that were once difficult to measure using conventional two-port measuring systems, can now be completely and accurately tested.

The N4413A S-parameter test set requires the N4425A Balanced Measurement System software or the N1930A Physical Layer Test System software for control of the 4-port VNA system, calibration, and data display and analysis.

Please note, this test set is not subject to a calibration test. The test set’s performance characteristics are parameters that the product is expected to meet before it leaves the factory. A functional test can verify proper performance of all microwave components within the test set.

The following features apply to a complete balanced-measurement system:
  • Display conventional (single-ended) and mixed mode S-parameters
  • Re-normalize test data for non-50-ohm devices
  • Achieve high measurement accuracy with full four-port vector error correction
  • Perform fast, accurate, automatic calibrations with easy to use N4430A four-port electronic calibration (ECal) module
  • Calculate important parameters with powerful user-defined displays
  • Gain additional insight with time domain analysis option
  • Connector: SMA
  • Max. Frequency: 6 GHz
  • Min. Frequency: 50 MHz
  • Channels: 4
  • Test set: si
 € 1.500,00
