HP Agilent Keysight, E3616A

You are here: Power Supply (DC) » Single output

HP Agilent Keysight, E3616A
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
The Agilent E3616A Power Supply offers essential features for a tight budget. The single output, 60W, E3616A provides a small, compact size for bench use; low-noise and excellent regulation; and dual-range outputs. The Agilent 60W, single output E3616A is a reliable and convenient power for benchtop use, and offers solid performance and a variety of basic and enhanced capabilities.

Output Ratings (Maximum current is derated 1% per °C between 40° to 55°C)

  • Range 1: 0 to 35 V, 0 to 1.7 A
  • Range 2: NA
  • Power (max): 60 W

Ripple & Noise from 20 Hz to 20 MHz

  • Voltage rms: 200 µV
  • Peak-to-Peak: 1 mV

Load & Line Regulation

  • 0.01% + 2 mV

Meter Resolution

  • Voltage: 10 mV (0-20 V), 100 mV (>20 V)
  • Current: 1 mA
  • Max current: 1.7 A
  • Display: LED
  • Max. Voltage: 35 V
  • Min. Voltage: 0 V
 € 300,00
