HP Agilent Keysight, 8901A
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description

The Agilent Technologies 8901A modulation analyzer combines the capabilities of several RF instruments to give complete, accurate characterization of modulated signals in the 150 kHz to 1300 MHz frequency range. It very accurately measures modulation and recovers the modulation signal, determines RF frequency and measures RF power.

  • Measures AM and FM to 1% accuracy
  • Measures RF frequency
  • Measures RF power
  • Low internal noise
  • Completely automatic
  • Max. Frequency: 1300 MHz
  • Min. Frequency: 150 KHz
  • Min. Level: 12 mVrms
  • Modulation: AM/FM
