HP Agilent Keysight, 34901A
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description

The Keysight 34901A module for the 34970A/34972A Data Acquisition/Switch Unit is the most versatile multiplexer for general purpose scanning. It combines dense, multi-function switching with 60 channel/second scan rates to address a broad spectrum of data acquisition applications.

Two- and four-wire channels can be mixed on the same module. Two additional fused inputs (22 channels total) route up to 1A of current to the internal DMM, allowing ac and dc current measurements without the need for external shunt resistors.

Features
  • 20 Channel Multiplexer
  • Two- and four-wire scanning
  • 300 V switching
  • 60 ch/s scanning
  • Built-in thermocouple reference junction
Price
 € 240,00
