Fluke, 5100B
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
The Fluke 5100B Calibrator is among the worlds leading calibrators for analog and digital multimeters to 4.5 digits. The 5100B calibrates precision meters that measure AC or DC Voltage (0-1100V), AC or DC current (200 uA-2A), and Resistance (1 ohm to 10 Mohms).

Fluke 5100B Accuracies are: DC voltage and resistance (0.005%), DC current (0.025%) AC Volts (0.05%) and AC current (0.07%).

Enhanced capability is also available with the 10 MHz Wideband Option and the capability to directly drive the Fluke 5220A 20A Transconductance Amplifier and the Fluke 5205A Precision Power Amplifier.

The Wideband Option (03) is an accurate, low-noise, flat alternating voltage source that allows the 5100B to be used for calibrating wideband voltmeters.
Features
  • Current: 0 - 2A
  • Interface: GP-IB
  • Resistance: 1 - 1Mohm
  • Voltage: 0 - 1100V
  • Current: 0 - 2A
  • Interface: GP-IB
  • Resistance: 1 - 1Mohm
  • Voltage: 0 - 1100V
