Xantrex, XKW 33-33
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description

XKW is the smart choice for OEM applications where high power and a wide adjustment of output voltage or current is required in a compact configuration. It is ideal for research, product development and production test applications such as R&D, magnet control, product design, ATE, process control, electroplating and burn-in. There are nineteen 1000 watt and 3000 watt XKW models available.

High frequency conventional PWM switching is used to achieve high power density in compact 19-inch rack packages: 1.75 inches (1 U) high for the 1000 watt models and 3.5 inches (2U) high for the 3000 watt models. XKW features include standard analog control, parallel or series connection of multiple units for increased current or voltage, and constant voltage or current operation with automatic crossover and mode indication.


    • External shutdown, external indicator signals
    • Remote/local modes
    • Remote sense, 1 V line loss compensation
    • LabView® drivers
    • OVP, current limit, thermal protection
    • CE, CSA, IEC approvals

    • GPIB Interface Card (16 Bit)
    • Isolated Interface Card (ISOL)
    • Locking knobs for front panel controls
  • Voltage range 0 - 33 V
  • Current Range 0 - 33 A
  • Max power 1 kW
  • Display LED
  • Constant Current Mode (CC)
  • Max current: 33A
  • Display: LED
  • Interface: GPIB (opt)
  • Max. Voltage: 33V
