The 38XR is a true RMS digital multimeter with optical PC interface. The XR series of multimeters is designed for electronic, electrical, plant maintenance and HVAC use.
For designing and troubleshooting electronics, industrial automation and control systems, the 38XR deliver the highest safety rating available – CAT IV 600 V and CAT III 1000 V. The features include temperature, capacitance, frequency, 4-20mA loop current percentage, backlight and PC interface.
Wavetek Meterman, 38XR
You are here: MULTIMETER » Digital Handheld
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
Features
- Frequency to 10 MHz, capacitance to 400 μF temperature to 2372 ºF
- Duty cycle, dBm and 4 to 20 mA loop current test
- 1000 V/750 V dc/ac True RMS, ac + dc input
- 10 Amps ac/dc, fully safety fused
- Resistance to 40 MΩ
- Continuity beeper
- Min/Max, Average, Relative, Peak, and Data Hold
- Bright blue backlight
- Auto power off to save battery life
- RS232 Output for measurement recording
- Separate door for easy battery and fuse access
- CAT IV 600 V, CAT III 1000 V, highest rating
- AAC Max: 10A
- ADC Max: 10A
- Interface: Optical for PC
- VAC Max: 750V
- VDC Max: 1000V
