TTi, EX752M

You are here: Power Supply (DC) » double

TTi, EX752M
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description

The EX-R series of compact mixed-mode regulated power supplies offers output power from 175 → 420W. The models have high resolution four digit meters and switchable remote sense terminals.

  • Mixed-mode regulated with linear final regulation
  • Constant voltage or constant current with automatic cross-over
  • 4 digit meters with 10mV and 1mA resolution
  • Switchable remote sense terminals for perfect regulation at the load
  • DC output switch enables voltage/current setup without load connected
  • Safety terminals accept fixed shroud 4mm plugs plus forks and wires
  • Silent fan-free convection cooling all models except EX2020R & EX4210R (intelligent fan cooling)
  Dual outputs with three modes of operation:
    2 x 75V/2A
    1 x 75V/4A
    1 x 150V/2A
  Independent digital voltage and current meters
    for each output with 100mV and 10mA resolution
  Constant voltage or constant current operation
  Compact design uses less bench space
  Silent fan-free cooling
  DC output switches, automatic mode indication

  Touch-proof safety terminals
  • Max current: 4A
  • Max. Voltage: 150V
