Tektronix, TDS820
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description

The Tektronix TDS820 Digitizing Oscilloscope offers 6 GHz bandwidth, 2 ch, 50 KS/s, monochrome display, 14 bits vertical resolution, 15K record length. Includes floppy, GPIB. Insta-Vu acquisition with color display.

TDS820 includes floppy, Centronics, RS-232 and GPIB. Intuitive user interface and multiprocessor DSP design. Complex design and debug tasks are streamlined with powerful triggering and automatic measurement capability.

The TDS820 Digital Sampling Oscilloscope is ideal for:

- Telecom Service and Manufacturing

- Semiconductor Characterization

- Digital System Design and Characterization

- Electronic Mask Drawing and Display

- Automatic Pass/Fail Limit Testing



Technical details:

  • 2 channels
  • Input Impedance: 50 Ohm
  • SMA Connector
  • 6GHz Bandwidth
  • Rise Time = 58 ps
  • Vertical Resolution: 14 bits
  • Time/division range 1ps to 5 ms/div
  • Max Operating Input Voltage: 2 Vpp ±  3 Vdc
  • Trigger Source: External input, internal rate generator, CH1, CH2
  • 2 GHz External Trigger Bandwidth
  • 1 GHz Internal Trigger Bandwith
  • CRT Monitor 640x480



  • Channels: 2
  • Display: CRT
  • BandWidth: 6 GHz
