Rohde & Schwarz , SPN

You are here: Function Generator » Digital

Rohde & Schwarz , SPN
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description

Technical details:

  • Frequency range: 1 Hz - 1.3 MHz
  • Output level: 0.1 mV to 10 V
  • Output impedance of 600-ohms, 50-ohms or 5-ohms
  • 5 digit display
  • Readout: V, mV, dBV, dBm
  • Can also be swept extern in linear or log modes
  • Squarewave TTL output also provided
  • IEC / IEEE 488 Bus controllable
  • Sine and square signal
  • Max. Frequency: 1.3 MHz
  • Min. Frequency: 1 Hz
  • Max. Level: 10 V
  • Min. Level: 1 mV
  • sweep: Extern
Price
 € 250,00
