Marconi, 2955A
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
The Marconi 2955A Radio Communications Test Set provides comprehensive testing facilities for AM/FM/0M transceivers to 1000MHz. Single key mode selection for transmitter, receiver and duplex testing. Full duplex facility tests radio telephones and cross-band repeaters. Menu-driven CRT display with store and recall for standard settings. Built in self test and operator guide. Operation from any standard AC supply up to 400Hz or vehicle supply.

  • Comprehensive testing for AM/FM/ØM transceivers to 1000MHz
  • GPIB or RS232 for full instrument control
  • Digital scope
  • DTMF and DCS encoders/ decoders
  • Precision digital readouts and autoranging bar charts for rapid testing
  • Menu driven CRT display with 26 stores for recall of standard settings
  • System checking of simplex transceivers in less than 3 seconds
  • Built-in self test and operator guide
  • Power supply: 220V
  • Dynamic range spectrum analyzer: not included
  • Max. Frequency: 1000 MHz
  • Min. Frequency: 400 KHz
  • Power range: -135/-15 dBm (N) / -115/+5 dBm (BNC)
