HP Agilent Keysight E3646A DC Power Supply Double
You are here: Power Supply (DC) » double
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
The E3646A 60 W dual output bench power supply offers dual-range flexibility with a low and high voltage range. The low voltage range allows the power supply to output more current. The E3640 Series has models with single and dual outputs — easily automate tests with GPIB or RS232.
Features
Output ratings (0°C to 40°C) two outputs
- Range 1: 0 to 8 V / 3 A
- Range 2: 0 to 20 V / 1.5 A
Programming accuracy (25 °C ± 5 °C), ± (% output plus offset)
- Voltage: < 0.05% + 10 mV (< 0.1% + 25 mV for output two of Keysight E3646A, E3647A, E3648A, E3649A)
- Current: < 0.2% + 10 mA
Ripple and noise 20 Hz to 20 MHz
- Normal mode voltage: < 5 mVpp / 0.5 mVrms
- Normal mode current: < 4 mArms
Readback accuracy (25 °C ± 5 °C), ± (% output plus offset)
- Voltage: < 0.05% + 5 mV (< 0.1% + 25 mV for output two of E3646A, E3647A, E3648A, E3649A)
- Current: < 0.15% + 5 mA (< 0.15% + 10 mA for output two of E3646A, E3647A, E3648A, E3649A)
- Max current: 3A
- Display: VFD
- Interface: RS232 - GPIB
- Max. Voltage: 20V
Price
€ 430,00
