HP Agilent Keysight, 53220A

You are here: Frequency Counter » Up to 18 GHz

HP Agilent Keysight, 53220A
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
Frequency counters are depended on in R&S and in manufacturing for the fastest, most accurate frequency and time interval measurements. The 53200 Series of RF and universal frequency counter/timers expands on this expectation toprovide you with the most information, connectivity and new measurement capabilities, while building on the speed andaccuracy you’ve depended on with Keysight Technologies, Inc. time and frequency measurement expertise.Three available models offer resolution capabilities up to 12 digits/sec frequency resolution on a one second gate. Single-shot time interval measurements can be resolved down to 20 psec. All models offer new built-in analysis and graphingcapabilities to maximize the insight and information you receive.
  • Two 350 MHz input channels, plus optional third channel (6 GHz or 15 GHz)
  • 12 digits/second resolution, 100 psec time interval resolution
  • Built-in math analysis and color, graphical display (trend and histogram)
  • Optional: Lithium Ion Battery
  • BenchVue software enabled: Do more with your PC and instrument together, no programming required. Easily control your counters, quickly build automated tests and log data for faster analysis and save precious time.
  • Max. Frequency: 350 MHz
  • Min. Frequency: 0.001 Hz
  • Channels: 2
  • Digit: 12
  • Resolution: 0.001 Hz
  • Sensibility: 20mV
