HP Agilent Keysight, 6634A
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
The 6634A Power Supply is a 100 watt, single output, series pass regulated supply is rated 100 V @ ±1 A. Both the voltage and current output can be programmed for either CV or CC operation. A built-in DCM and precision current shunt measure (readback) the actual power supply output. The internal HP-IB interface allows for complete programmability, including status reporting and interrupt generation with user designated fault conditions.
  • Voltage 0-100V
  • Current 0-1A
  • Display LCD
  • CV -CI
  • Remote sensing
  • Selftest
  • GPIB
  • Max current: 1A
  • Interface: GPIB
  • Max. Voltage: 100V
  • Min. Voltage: 0V
