The Agilent HP 6063B is a 250 W, single output electronic load, ideal for evaluation of DC power sources and power components in bench applications. The 6063B has built-in measurement functions that make it convenient for testing single output applications in areas such as research and development, production, and incoming inspection.
HP Agilent 6063B
You are here: ELECTRONIC LOAD » STAND ALONE
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
Features
- Current 0 - 10 A
- Voltage 3 - 240 V
- Max Power 250 W
- Costant Current Mode:
- Range 0 to 1 A, 0 to 10 A
- Accuracy 0.15% ±10 mA
- Regulation 8 mA
- Costant Voltage Mode:
- Accuracy 0.12% ±120 mV
- Regulation (w/remote sense) 10 mV
- Costant Resistance Mode:
- Range 24 to 10 KΩ ,240 to 50 KΩ
- Accuracy: 24 Ω: 0.8% +/-200 mΩ (with ³1 A at input) / 10 KΩ/: 0.3% +/-0.3 mS (with ³24 V at input) / 50 KΩ: 0.3% +/-0.3 mS (with ³24 V at input)
Price
€ 800,00
