HP Agilent Keysight 6644A 210 Watt System Power Supply 60V 3.5A GPIB

You are here: Power Supply (DC) » Single output

HP Agilent Keysight 6644A 210 Watt System Power Supply 60V 3.5A GPIB
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
This series of 200 W linear-regulated DC power supplies is designed to maximize the throughput of DUTs through the manufacturing test process with fast up and down programming time.
Features

Output Ratings

  • Output voltage: 0 to 60 V
  • Output current (40° C): 0 to 3.5 A
  • Maximum current (50° C/55° C): 3.2 A/3 A

Programming Accuracy at 25°C ±5°C

  • Voltage 0.06% + 26 mV
  • Current 0.15% + 4.1 mA

Ripple & Noise (20 Hz - 20 MHz)

  • Voltage rms: 500 µV
  • Voltage peak-to-peak: 5 mV
  • Current rms: 1.5 mA
  • Max current: 3.5A
  • Max. Voltage: 60V
  • Min. Voltage: 0V
